Zhangjiagang Micmachinery.Сo.,Ltd

This is a kind of professional filling machine for Pure beer which applies to PET bottle. It is made of high quality SUS304 stainless steel. Main components are processed precisely by CNC machine tool. The machine adopts advanced photo electricity to detect running status. No bottle no filling system.

This beer bottling machine mainly used for Beer filling operation and consists of rinsing, filling and capping units. The whole procedure is full auto, and suitable for glass bottle and aluminum steel-proof caps for filling vodka, wine, sauce and etc. Equipped with 18 rinsing, 18 filling and 6 capping heads. Filling speed is 3000 – 4000 BPH.

This machine is of good reliability of mechanical operation, perfect functions in rinsing, filling, capping, disinfecting and sterilizing, realizing filling the sterile beer into the sterile container in a sterile environment. Equipped with 18 rinsing, 18 filling and 1 capping heads. Filling speed is 1000 – 2500 BPH.

The machine is applicable for equal pressure filler and capper of beer industry. Filling temperature is 5 oC. To operate the machine needs compressed air supply with a pressure of 0.7 MPa. Filling volume is 0.1 – 1.25 L. Equipped with 24 washing, 24 filling and 6 capping heads. Filling speed is 4000 BPH based on 0.5 L bottle.

The machine is applicable for glass bottle filling and capping of craft beer. To operate the machine needs compressed air supply with a pressure of 0.7 MPa. Filling volume is 0.1 – 1 L. Equipped with 24 washing, 24 filling and 8 capping heads. Filling speed is 2000 - 6000 BPH based on 0.33 L bottle.

Designed for the aseptic filling of pure beer. This machine is of good reliability of mechanical operation, perfect functions in rinsing, filling, capping, disinfecting and sterilizing, realizing filling the sterile beer into the sterile container in a sterile environment. Equipped with 12 washing, 8 filling and 1 capping heads. Filling speed is 300 - 500 BPH based on 0.33 L bottle.

The machine is rotary design, it is used for production of various kinds of beer. It uses pressure filling, liquid surface positioning. The machine is automatically controlled. Equipped with 32 washing, 32 filling and 8 capping heads. Filling speed is 8000 - 10000 BPH.

This machine adopted negative pressure or isobaric filling system, suitable for beer, wine and etc. It has the characteristics of filling reposefully, at high speed, liquid level control, capping reliably, frequency conversion timing, less material loss. Equipped with 4 -10 filling and 4 - 10 capping heads. Filling speed is 200 - 800 cans per hour.

This machine adopts isobaric pressure filling system which is applicable for beer (Cold filling temperature at 0-4 degrees Celsius). It has the characteristics of filling reposefully, high speed, liquid level control, capping reliably, frequency conversion timing, less material loss. Equipped with 12 filling and 1 sealing heads. Filling speed is 1000 - 2000 cans per hour.

This machine is applicable for beer (Cold filling temperature at 0-4 degrees Celsius). It has the characteristics of filling reposefully, high speed, liquid level control, capping reliably, frequency conversion timing, less material loss. Equipped with 18 filling and 1 sealing heads. Filling speed is 1000 - 2500 cans per hour.
